INP-DCDC bidirectional converter is a non-isolated DC to DC energy converter. This product is a bidirectional DCDC. The input to output is BUCK mode, and the output to input is BOOST mode. INP-DCDC can be used with INP energy storage converter to broaden the battery voltage range and support DC voltage range 300-900V. It also has MPPT control and can support photovoltaic access.
Share
Features
01
Ultra-wide DC voltage range: 300-900V.
02
Equipped with MPPT control all the way to support photovoltaic access.
03
Supports multiple battery types, complete converter and battery protection functions.
04
4-way staggered parallel connection, low output ripple current and friendly to battery.
05
The power device of the whole machine uses silicon carbide MOSFET, which is smaller and more efficient.
06
Supports multiple working modes: low-voltage side constant voltage, low-voltage side constant current, low-voltage side constant power, high-voltage side constant voltage, and high-voltage side constant current.
Product principle
| Product model | INP DCDC 50/0.3-W | INP DCDC 100/0.3-W |
| Low voltage side DC voltage | 300V~900V, full load 310V~900V | 300V~900V, full load 360V~900V |
| High voltage side DC voltage | 300V~900V, full load 500V~900V | 300V~900V, full load 500V~900V |
| Rated power | 50kW | 100kW |
| Maximum current on low voltage side | 165A | 275A |
| Maximum current on high voltage side | 120A | 200A |
| Voltage measurement accuracy | ±1% | |
| Current measurement accuracy | ±1% | |
| MPPT function | Have | |
| maximum efficiency | ≥99% | |
| weight | 28kg | |
| working temperature | -25℃~+60℃ (> derating at 45℃) | |
| Size | W520mm*D600mm*H133mm | |
